150 cm sweeper for the 4FARMER tractor with a basket
The sweeper, as the name suggests, is designed to remove dirt from surfaces such as roads, squares, sidewalks, areas covered with asphalt, paving stones or concrete. Sweepers will find their application in the municipal, agricultural and construction industries. In addition, they can be used in winter after dismantling the basket as a snow blower in order to get rid of the layer of snow. These are very versatile machines, facilitating cleaning, allowing for effective and quick work. On the market, we can find sweepers dedicated to a tractor (3-point linkage) or a forklift .
The 150 cm sweeper with a 4FARMER basket is attached to the tractor through the rear linkage Cat I and Cat II and is driven by the power take-off shaft (PTO). The working width of this model is 150 cm.
How does a sweeper work?
The cleaning mechanism is a roller on which dense bristles made of polypropylene are placed. It is powered by the power transmitted from the tractor. The sweeper is equipped with a basket located behind the roller. The roller, rotating, removes the impurities, collecting them in the basket. This container is opened mechanically.
The effective operation of the sweeper for the tractor is ensured by the guide wheels, enabling the appropriate setting of the sweeper to the surface on which we are working. It should be remembered that too much pressure of the bristles on the surface to be cleaned will cause excessive wear.
Specification
Condition
New
Production
Polish product
Mark
4Farmer
working width (mm)
1500
Drive
PTO (PTO)
NEXT DOOR
3 point
KAT I
KAT II
Equipment
Basket - opened manually
Roller diameter (mm)
600
Weight (kg)
300
Color
Red
Bristle material
Polypropylene
Overall width (mm)
1800
Brush rotation (rpm)
140 - 160
Operating speed (km/h)
up to 10
