Rod End / Left / 63 x 87 mm / Kubota / 67121-56520

Steering rod LH (RH rod %C5% BCki-kierownicze-/34311-ko %C5% 84c %C3% B3wka-dr %C4% 85 %C5% BCka-63-x-87-mm-rh-kubota-b1402b1600b1750b2400-67121-56530.html">67121-56530 ) with a total length of 88 mm and a height of 63 mm for tractors Kubota brand series Kubota B1402, Kubota B1550, Kubota B1600, Kubota B1700, Kubota B1750, Kubota B2100, Kubota B2400, Kubota B2410, Kubota B2710, Kubota B2910, Kubota B3200, Kubota B3300, Kubota B4200, Kubota B5200, Kubota B6200, Kubota B7100 and others

The tie rod end, or tie rod with its ends, is a steering component that connects the wheels to the steering gear. Proper installation of this component directly affects the wheel angle and, consequently, the vehicle's handling characteristics. The most common visible signs that a tie rod needs to be replaced are play in the steering system or visible abnormal tire wear. Remember that the good condition of the tie rod ends improves driving safety and extends tire life.

Dimensions :

• total length: 87 mm,
• height: 63 mm,
• head diameter: 34 mm,
• head height (see drawing): 63 mm,
• cone height: 34 mm,
• cone diameter (see drawing): 11 / 12 mm,
• thread: M10 x 1.25 / M12 x 1.25,
• thread length: 12 / 45 mm,
• original part numbers: 67121-56520,
• reference numbers: 6A100-56520, 67950-56520,
• part numbers: 67121-56520.

Tractor models :

• Kubota B1402,
• Kubota B1550,
• Kubota B1600,
• Kubota B1700,
• Kubota B1750,
• Kubota B2100,
• Kubota B2400,
• Kubota B2410,
• Kubota B2710,
• Kubota B2910,
• Kubota B3200,
• Kubota B3300,
• Kubota B4200,
• Kubota B5200,
• Kubota B6200,
• Kubota B7100.

The first signs of steering rack wear include play in the steering wheel, steering wheel vibration, and delayed steering wheel response to slight steering wheel movements. Tie rod end wear or damage is often caused by other malfunctioning components or improper driving and operation of the tractor.

Magazine: K18:E25:S02

*Photos are for illustrative purposes only and may differ in detail from the delivered product due to differences in production over the years.
