Product description
Hydraulic piston pin , hydraulic lift piston rod with dimensions 32 x 183.5 for LS Tractor tractors.
The push rod , or the push rod of a tractor's hydraulic piston, is a component whose primary function is to transfer longitudinal load, pushing out a piston housed in a cylindrical body. The push rod is mounted on a pin on one side, while the rounded part on the other freely engages the jack piston socket. This piston, when activated by a lever movement, performs a sliding motion, generating the appropriate fluid pressure and thus lifting the jack. The jack piston returns to its original or preset position (after previously moving the jack lever) under its own weight or under the weight of the machine mounted on the jack, and in simpler designs under the influence of previously generated hydraulic fluid pressure (some hydraulic jacks use return springs).
Tractor models:
- LS U43, U50, U60
- LS PLUS70, PLUS80, PLUS90, PLUS100
- LS R41, R41HST, R43, R43HST, R50, R50HST
- LS ULTRA55, ULTRA65
- LS P7040
- LS XR45, XR45HST, XR50, XR50HST, XR60
- LS XP8084, XP8094, XP8101, XP7.101
- LS XU6158, XU6168
- LS MT340, MT357
Dimensions :
- length: 183.5 mm,
- diameter: 32 mm,
- part numbers: A1826127
Warehouse : L01:J-1-4
*Photos are for illustrative purposes only and may differ in detail from the delivered product due to differences in production over the years.
