O-ring + Back up Ring / 5.50 x 62 mm / Kubota L2201 / L2250 / L2350 / L2600 / L2800 / L3000 / L3301 / L3408 / L3800

O-ring for the three-point linkage hydraulic lift piston (o-ring 04811-00650, ring 34220-37380) with an inner diameter of 62 mm and a thickness of 5.50 mm for Kubota tractors of the Kubota L2201, Kubota L2250, Kubota L2350 , Kubota L2600 , Kubota L2800, Kubota L3000, Kubota L3301, Kubota L3800 series and others.

An O-ring is a type of circular seal available in a wide range of sizes and diameters. The primary purpose of an O-ring is to seal in areas where high pressure is not present, but also where it is subjected to high pressure. Under high pressure, an O-ring adopts fluid-like properties (surface tension, plasticity, etc.), providing excellent sealing properties.

A back-up ring is a rigid ring, usually made of plastic, that protects O-rings from damage caused by the high pressure and temperature inside a hydraulic system during operation. A back-up ring (also known as a backup ring) is a ring whose primary function is to prevent the O-ring from being forced into the gap between the sealing surfaces and to protect the seal from deformation, which can occur when the seal is subjected to high pressure and temperature. When pressure acts on the O-ring from two directions, a back-up ring is used on both sides of the O-ring.

Dimensions (O-ring):

• inner diameter: 62 mm,
• thickness: 5.50 mm,
• original part numbers: 04811-00650,
• comparative numbers: -,
• part numbers: 5-18-107-02.

Dimensions (back up ring):

• inner diameter: 62.50 mm,
• thickness: 2.00 mm,
• original part numbers: 34220-37380,
• comparative numbers: -,
• part numbers: 5-18-107-02.

Tractor models :

• Kubota L2201,
• Kubota L2250,
• Kubota L2350,
• Kubota L2600,
• Kubota L2800,
• Kubota L3000,
• Kubota L3301,
• Kubota L3800.

Magazine: K18:F39:S01

*Photos are for illustrative purposes only and may differ in detail from the delivered product due to differences in production over the years.
