Seger ring Ø 36 / LS MT3.50 / LS MT3.60 / S810036001 / 40029276
search
1 osoba ogląda ten produkt
  • Seger ring Ø 36 / LS MT3.50 / LS MT3.60 / S810036001 / 40029276
  • Seger ring Ø 36 / LS MT3.50 / LS MT3.60 / S810036001 / 40029276
  • Seger ring Ø 36 / LS MT3.50 / LS MT3.60 / S810036001 / 40029276

Seger ring Ø 36 / LS MT3.50 / LS MT3.60 / S810036001 / 40029276

Product code: 40029276
Brand
Country of production
View other model
zł4.33
Includes VAT 23%

Lowest price from 30 days: zł4.33

Product description

Internal seger ring , with a snap ring with an internal diameter of 33.20 mm , external diameter of 39.20 mm , height of 42.50 mm and a thickness of 1.75 mm for LS Tractors , series LS MT3.50, LS MT3.60 and others for:

  • PTO / PTO shaft,
  • 4 x 4 drive shaft,

External spring ring called a seger ring from the name of the company that first patented its invention. A safety ring is an element of a mechanical system that is assembled to prevent the movement of moving parts or machine parts. Bearings, bushings, gears are placed on the shaft and axles, and not secured with seger rings, they can be given axial shifts. Seger rings are divided into two groups, for shafts, pins and for holes, and they differ from each other in shape at the place of mounting holes.

Dimensions:

  • inner diameter: 33.20 mm,
  • outer diameter: 39.20 mm,
  • height: 42.50 mm,
  • hole diameter: 2.50 mm,
  • thickness: 1.75 mm,
  • part numbers: 40029276, S810036001.

Tractor models:

LS Tractors :

  • LS MT3.50,
  • LS MT3.60.

Warehouse :
M01: M26: S03

Specifications

Condition
New

Reviews of Seger ring Ø..

Traktor.com.pl S.C. Wojciech i Miłosz Początek Reviews with ekomi-pl.com

This product has no reviews yet.

We collect reviews from verified Customers after the purchase of the product.

Write your review

Review form will be here

Questions & Answers

Why is regular filter replacement (oil, air, fuel) crucial for a mini tractor?

User
Ekspert Traktor.com.pl – Doradca techniczny • 17.02.2026
Regular filter replacement is the easiest way to extend the life of an engine from brands like Kubota or Yanmar. The oil filter removes metallic contaminants generated during operation, the air filter protects the cylinders from field dust, and the fuel filter prevents water and dirt from damaging the precision injection system. We recommend replacing filters every 50-100 operating hours or at least once per season to ensure optimal engine performance.

How to properly select and sharpen mower blades for a Japanese tractor?

User
Ekspert Traktor.com.pl – Doradca techniczny • 17.02.2026
When selecting mower blades, consider the mower deck model and the blade length and center bore diameter. Maintaining blade balance is crucial when sharpening – an unbalanced blade causes vibrations that damage the hub bearings. Remember that sharp blades mean healthier grass, a cleaner cut, and less strain on the engine of your Iseki or Mitsubishi tractor.

How to identify the correct V-belt size and how to care for it?

User
Ekspert Traktor.com.pl – Doradca techniczny • 17.02.2026
It's best to read the markings on the side of the old V-belt. If they are illegible, measure the belt width and its outer length (La). On Shibaura and Hinomoto tractors, it's important to regularly check the belt tension – too loose a belt will cause slippage and faster wear, while too tight a belt can cause alternator or water pump bearing failure.
