Hydraulic oil filter 1"1/2-16UNF / LS Tractor / TRG823 / 40372541 / 40030262 / 40211116

Hydraulic oil filter with an outer diameter of 134 mm , height of 170 mm with a thread of 1"1/2-16UNF for tractors and mini tractors LS Tractor series LS PLUS 70, LS PLUS 80, LS PLUS 90, MT5.68, MT5.73 and others

The main function of a hydraulic filter is to clean the hydraulic oil, retaining all impurities that enter the hydraulic system or are generated during tractor operation, such as solid (mineral) particles. The hydraulic filter should be replaced every time the hydraulic oil is changed or when the vehicle is frequently used. In the case of mini tractors, this is approximately every 100 operating hours for used tractors. The procedure for replacing the hydraulic filter in new tractors is thoroughly described in the machine's instruction manual, and usually occurs after the first 50 operating hours (at least three cycles). The hydraulic filter is usually a metal filter with a thread and seal , mounted near the tractor's transmission, directly in the hydraulic system's oil flow path, most often on the underside of the transmission or under the tractor's floor. Regularly replacing the hydraulic filter guarantees trouble-free operation and ensures that the hydraulic system is free of foreign objects that could damage the tractor or negatively impact its performance, reducing its performance parameters.

Dimensions :

• outer diameter: 134 mm,
• height: 170 mm,
• base diameter: 139 mm,
• thread: 1"1/2-16UNF,
• gasket diameter: inner 99 mm, outer 110 mm,
• weight: 1,520 kg,
• part numbers: 40372541, 40030262.

Tractor model :

LS Tractor :

• LS PLUS70,
• LS PLUS80,
• LS PLUS90
• LS MT5.68
• LS MT5.73

Regular replacement of the hydraulic filter is a guarantee of trouble-free operation of the machine and the certainty that there are no foreign bodies in the hydraulic system that can damage our tractor or negatively affect the operation of the machine, reducing its operating parameters.
