Engine Piston / Ø 70 mm / STD / Mitsubishi K3C / VST Fieldtrac MT180

Engine piston (rings MM432983) with an outer diameter of 70 mm and an overall height of 68 mm for VST Fieldtrac MT180 series tractors with Mitsubishi K3C engines and others. The engine piston is a moving part responsible for converting gas and combustion energy into the crankshaft, and thus into engine power. The piston is connected to the crankshaft by a connecting rod with pin connections. At the top of the piston are annular channels for mounting the piston rings, and in the center is a hub for connecting to the connecting rod. At the top is the so-called crown, which can have different shapes depending on the engine type. Due to the very harsh operating conditions, engine pistons are most often made of aluminum and silicon alloys.

Dimensions:

• diameter: 70 mm,
• height: 60 / 68 mm,
• pin hole diameter: 19 mm,
• pin diameter: 18.90 mm,
• pin length: 60 mm,
• distance from the end of the pin hole to the lower edge of the piston: 12 mm,
• distance from the edge of the pin hole to the top edge of the piston: 30 mm,
• ring groove width (MM432983) from the top of the piston: 2.50 / 2.50 / 2.50 / 4.00 mm,
• reference numbers: ACA97C00210A0,
• part number: MM435032X0K0.

Tractor models :

VST :

• VST Fieldtrac MT180.

Engine models:

• Mitsubishi K3C.

Magazine : M01:C21:S01

*Photos are for illustrative purposes only and may differ in detail from the delivered product due to differences in production over the years.
